STANDARD FEATURES:

  • Powered moveable workhead for off-center work allows operator to position the cylinder from left to right and front to back with the touch of a lever.
  • Cylinder activation is fingertip controlled, the more the hand lever is engaged the more the ram movement is accelerated. This allows the operator to control the proper speed of the task.
  • Pressure regulator to limit the ram pressure
  • Flat ram nose can be easily changed to allow the user to adapt the press to a specific job
  • Low pressure hydraulic system maintains lower oil temperatures, resulting in higher efficiency and safer operation
  • All hydraulic and mechanical parts are standard in the industry, and available throughout North America.

OPTIONS:



  • Moveable pedestal with height adjustment for ease and comfort of operator

Key features and specs

  • MODEL: GSP-100 46
  • POWER: 10 HP, 3 phase
  • TABLE: 48" x 72"
  • BORE: 8"
  • STROKE: 12"
  • RAM SPEED: -PRESS: 20 IPM RETURN: 26 IPM
  • CAPACITY: 100 TONS
  • WEIGHT: 10,000 LBS
  • DIMENSIONS (LxWxH): 88" x 108" x 80"
