Superior versatility.
Rapid-Air feeds offer unmatched production flexibility. Their cost-effective operation often justifies permanent installation on die sets to minimize job setup time.
Easy installation and removal make Rapid-Air units the most versatile type of feeding equipment available. Two bolts are all it takes to install one. Stroke length and speed adjustments are positioned for easy access.
Feed a variety of material in any direction.
All kinds of coil stock plus paper, plastic, wire, fabrics, foil, tubing, extruded and preformed shapes can be fed at short and long progressions, and at different production speeds. Rapid-Air feeds are unequalled in handling both thin and delicate materials. Several actuation options allow our feeds to be used on standard production presses, electric presses, hydraulic presses, wire forming machines, multi-slide machines and special machines.
We offer a comprehensive range of standard models to feed flat stock up to 16” (406mm) wide, .150” (3.81mm) thick, and in lengths up to 20” (508mm). Pulling capacities of up to 250 pounds (114kg) are available on heavy duty models. Our smallest feed is capable of 260 cycles per minute at a 2” (50.8mm) progression and can cycle much faster at shorter progressions. Special models are available to meet unusual feeding requirements
