Specifications

  • MODEL: 17 ½ LJA
  • CAPACITY: 60 TON
  • SERIAL#: 75452
  • STROKE: 5”
  • SHUT HEIGHT: 12 3/8” OVER BED
  • RAM ADJUSTMENT: 3”
  • BED AREA L-R x F-B: 32” x 22 ½”
  • RAM AREA L-R x F-B: 21” x 16” Flanged
  • SPEED: 86 SPM approx.
  • THROAT DEPTH: 11 ¼” approx.
  • SHANK HOLE DIAMETER: 2” ROUND
  • WIDTH of OPENING THROUGH FRAME: 15” approx.
  • DISTANCE FROM BED TO FLOOR 33-1/2”
  • MOTOR: 5 HP MAIN, 575/3/60
  • WEIGHT: 10,600 LBS approx.
  • DIMENSIONS (LxWxH): 79”x63”x112” approx.
  • FOB POINT: MISSISSAUGA, ON

REQUEST A QUOTE FOR THIS MACHINE

Fill out the form and send it through to our team and we can help you get started with your inquiry.
