Specifications:
- SHEET THICKNESS MAX. (Mild Steel): 3 mm 11 ga.
- WORKING LENGTH: 3200 mm 125.9”
- BACKGAUGE DEPTH (Standard): 10-1550 mm 0.4” – 61”
- BACKGAUGE ACCURACY: +/-0.1 mm +/-0.004”
- UPPER BEAM OPEN HEIGHT MAX.: 300 mm 11.81”
- CNC FOLDING BEAM ADJUSTMENT MAX.: 80 mm 3.15”
- CNC LOWER BEAM ADJUSTMENT MAX.: 80 mm 3.15”
- WORKING HEIGHT: 900 mm 35.43”
- AIR PRESSURE: 5 bar 72.5 PSI
- DRIVE POWER UPPER BEAM: 4.0 kW 5.5 HP
- DRIVE POWER FOLDING BEAM: 4.0 kW 5.5 HP
- FOLDING BEAM SPEED: 90º/s 90º/s
- UPPER BEAM SPEED: 40 mm/s 1.575”/s
- BACKGAUGE SPEED 10-1550 mm (0.4”-61”) 1.9 s 1.9 s
- YEAR OF MANUFACTURE: 2008
- WEIGHT: 9,480 lbs
- DIMENSIONS (LxWxH): 169” x 88” x 70”
