Specifications

Model IW-135SD-U

Serial 14089155

Year of manufacture 2014

Maximum punching pressure 135 ton

Maximum capacity (dia. x thickness) 1-1/4”x1-1/16”,  2″ x 11/16” (mild steel)

Throat 20″

Maximum stroke length 4”

Cycle/Min (3/4″) 28

Flat bar shear 24”x11/16”(16″ x 1″)

Blade length 24-3/8″

ANGLE SHEARING

At 90o shearing 6″ x 6″ x 11/16″

At 45º shearing 3-1/8”x3-1/8”x3/8”

BAR SHEARING

Round bar shear 2″

Square bar shear 2” x 2″

NOTCHING

Rectangular Notcher (w x d x t) 2″ x 3-1/2″ x 1/2”

Electrics 15hp

Weight (net) 8,710 lbs

Dimensions 98” x 35” w x 73” h
