APHS-37240
Serial # 17589
Bending Capacity Tons 264
Overall Bend Length 12’1”
Distance Between Side Housings 10’7”
Open Height above bed 20.8 inches
Stroke Length 10.2 inches
Closed Height 10.6 inches
Table Width 3.5 inches
Speed Advance 330 “/min
Pressing (Variable) 23.6 “/min
Return 260 “/min
Throat Depth16.1 inches
Bed Height Above Floor 34.6 inches
Bed Projection Below Floor 0 inches
Motor 30 HP
Oil Tank Capacity55 Gallons
Machine Height 114 inches
Machine front to back dimension 64 inches
Machine weight 29,700 lbs.
Year 2011
Machine left to right dimension: 184 inches
FOB point MISSISSAUGA, ON
Condition Pre-Owned
